Generator Excitation System with 100KW to 20MW Output Capacity, 110V to 690V Voltage Range, and 96% Efficiency for Stable Power Generation
Dettagli:
| Marca: | Wawushan |
| Certificazione: | ISO9001 |
| Numero di modello: | EX-202507 |
Termini di pagamento e spedizione:
| Minimum Order Quantity: | 1 |
|---|---|
| Prezzo: | 5000-60000USD |
| Imballaggi particolari: | Standard |
| Delivery Time: | 3 Months |
| Payment Terms: | T/T |
| Supply Ability: | 300 Set Per Unit |
|
Informazioni dettagliate |
|||
| VoltageRange: | Da 110 V a 690 V | Tipo: | Generatore sincrono |
|---|---|---|---|
| Frequenza nominale: | 50Hz | Dimensione: | 3Mx3Mx2.5M |
| Corrente nominale: | 5A | Tipo di controllo: | Regolatore automatico di tensione (AVR) |
| Disposizione: | Orizzontale | Intervallo corrente: | Da 0 a 500 A |
| Evidenziare: | 100KW to 20MW Generator Excitation System,110V to 690V Excitation System,96% Efficiency AVR Excitation System |
||
Descrizione di prodotto
Generator Excitation System
Output Capacity 100KW To 20MW Excitation System Optimized For Consistent Voltage Output And Generator Excitation Control
Product Overview
The Generator Excitation System is engineered to regulate and control generator voltage output, ensuring stable and reliable power supply across diverse applications. With advanced technology and precision engineering, this system delivers exceptional performance and efficiency for modern power generation setups.
Key Features
- Product Name: Generator Excitation System
- Current Range: 0 to 500A for optimal control
- Rated Frequency: 50Hz ensuring stable operation
- Runner Blade: Fixed type for consistent performance
- Dimension: Compact size of 3M x 3M x 2.5M
- Layout: Horizontal configuration for easy installation
- Highly reliable design for maximum efficiency
- Advanced technology to enhance generator output
- Robust construction ensuring long-term durability
Technical Specifications
| Parameter | Specification |
|---|---|
| Type | Synchronous Generator |
| Rated Current | 5A |
| Control Type | Automatic Voltage Regulator (AVR) |
| Mounting Type | Panel Mounted Or Cabinet Mounted |
| Input AC Voltage | 100V |
| Layout | Horizontal |
| Output Capacity | 100KW To 20MW |
| Rated Frequency | 50HZ |
| Runner Blade | Fixed |
| Efficiency | 96.20% |
Performance Highlights
Input Voltage
100V AC
Efficiency Rating
96%
Voltage Range
110V to 690V
Output Capacity
100KW to 20MW
Applications
The Wawushan EX-202501 Generator Excitation System is ideal for power plants, industrial facilities, and commercial power generation units where consistent voltage regulation is critical. Suitable for both small-scale power generation and large-scale industrial projects, including renewable energy applications such as hydroelectric and wind power plants.
Customization & Ordering
Wawushan EX-202501 Model
ISO9001 certified synchronous generator excitation system manufactured in China. Available in green color with compact dimensions of 3M*3M*2.5M.
Minimum Order
1 unit
Price Range
5000 to 60000 USD
Supply Capacity
300 sets per unit
Delivery Time
Approximately 3 months
Payment Terms
Primarily T/T
Support & Services
Comprehensive technical support including installation assistance, configuration, troubleshooting, and maintenance. Our experienced engineering team provides regular system diagnostics, performance evaluations, and preventive maintenance services to minimize downtime and ensure optimal operation.
Training & Documentation: Detailed training sessions and documentation provided to ensure safe and effective system operation.
